In mid-March, a Kinitics production KLA05 Linear Actuator reached a major milestone of 1 million cycles in the company’s Test Cell 1. The test apparatus includes a fully loaded KLA05 Linear Actuator, a KCA020 Controller and a PLC running a control system to repeatedly cycle the actuator while telemetry is recorded using a data acquisition system.
This 1 million cycle milestone confirms the reliability of the KLA Linear and its suitability for a wide range of applications.
Note: Due to concerns around the rapidly evolving coronavirus (COVID-19) pandemic, ASM International has cancelled the SMST Entrepreneurial Workshop.
The SMST (Shape Memory and Superelastic Technologies) Entrepreneurial Workshop takes place May 4-5 in Palm Springs, California, and provides education toward startup success for SMA entrepreneurs. As part of the workshop’s technical program, Kinitics Automation President Dean Pick will be presenting “Designing an SMA Actuator” at 10:30 a.m. on Tuesday, May 5.
For more information about the program and workshop, visit the event website: SMST Entrepreneurial Workshop
“Designing an SMA Actuator” abstract:
In bringing a Shape Memory Alloy (SMA)-based actuator to market, the designer should be aware of information gaps that exist when applying standard design methodology. These gaps can manifest into a disconnect between the desired performance specifications and the end result. SMA actuators can incorporate electrical, mechanical, thermodynamics, fluid dynamics, and material phase transformation aspects inside a single package. While common form factors for the active SMA element are commercially available there is no standard format for presenting the critical information needed to correctly apply the material. While it may be tempting to rely solely on a simple heat up and cool down process model to predict performance, this can lead to an oversimplification of the design problem. Safe working loads, material biasing, and fatigue life considerations can all have important ramifications late in the design phase and must be considered at an early stage, which necessitates a more in-depth analysis of the application’s requirements than for a non-SMA actuator. These gaps in standard design methodology can be bridged by having a material integrator as part of the design team from the early stages of development.
On March 12 a prototype Kinitics KLA Linear Actuator reached a major milestone: the actuator has been in operation holding a constant position for exactly one year.
The “long duration hold” test involves a prototype Kinitics KLA Linear Actuator, a load cell, and a position sensor arranged inside of a test apparatus. A Kinitics KCA020 AC Controller is used as part of a simple position-feedback control loop while test telemetry is recorded using a data acquisition system. The system has been running since March 12, 2018 in a relatively uncontrolled environment, with only occasional downtimes due to power interruptions. This one-year test milestone confirms the reliability of the KLA Linear Actuator in long-term positioning applications.
This video, shot at the IMTS show by Design World magazine, features Kinitics Automation president Dean Pick and Design World editor Lisa Eitel discussing the Kinitics KLA05 Linear Actuator and the Kinitics haptic device. The haptic device combines a KLA05 Linear Actuator and KCA020 Controller, and responds to user force by contracting a distance proportional to the amount of force applied. The device is used to demonstrate the simplicity of controlling the KLA05 Linear Actuator in a variety of applications.
The article is online at Design World as well as Linear Motion Tips. Read the online version of the article here: Shape Memory Alloy Linear Actuators: A New Option For Positioning. You can also check out the complete Design World issue online here: Design World September 2018.
Kinitics Automation announces the availability of the shape memory alloy-based KPP05 Piston Pump. Read the full press release here: Kinitics Automation Introduces the KPP05 Piston Pump.
Kinitics Automation will be exhibiting at the 2018 International Manufacturing Technology Show (IMTS) – the world’s leading trade show for industrial technology – in September. The company will be displaying its KLA05 Linear Actuator and KPP05 Piston Pump products, in addition to the KLA05 test stand that demonstrates the actuator and its capabilities. For more details on the show, see our IMTS 2018 page.
The June 2018 issue of Tech Briefs includes an article covering the use of shape memory alloy in linear actuators, based on the Bundled Wire technology developed by Kinitics Automation. The article, written by Kinitics president Dean Pick, is titled “Shape Memory Alloys Achieve High Force and Precision” and covers the basic concepts of shape memory alloys, how SMAs can be bundled to achieve the desired performance in a high-force linear actuator, and some of the resulting capabilities. Tech Briefs magazine features cutting-edge technologies developed by innovators within NASA, the military, federal laboratories, universities and commercial companies, and is available in print and digital formats.
Read the article online here: Shape Memory Alloys Achieve High Force and Precision
Download the June 2018 issue of Tech Briefs here: Tech Briefs
This video explains some of the KLA05 actuator’s features and how if fits into a control system, and shows the actuator in action as it is run through a sequence of three lifts on the Kinitics Test & Development Stand to showcase those features. In the first sequence, the actuator performs a simple dead-lift of 74 kg (163 lb) to its end of travel; in the second lift, the actuator holds the weight at two precise intervals for a period of time; and in the final lift, the actuator holds the weight at a set displacement for 10 seconds.
